Exerpeutic Pro Stride 21 - Hand Pulse Handlebar Installation

8. Hand Pulse Handlebar Installation
Insert the Sensor Wire I (93) from the Front Post (2) into the hole on the
Hand Pulse Handlebar (15) and then pull it out from the Hand Pulse
Handlebar (15).
Attach the Hand Pulse Handlebar (15) onto the Front Post (2) with two
M8x25mm Bolts (106). Tighten bolts with the M5 Allen Wrench provided.
Hardware:
ASSEMBLY
19
(106) Bolt M8x25mm
2 PCS
Allen Wrench (M5)
Tool:
