12. Computer Installation
Remove four M5x10mm Bolts (32) from the back of the Computer (99).
Remove bolts with the Hex Tool with Phillips Screwdriver provided.
Connect the Sensor Wire I (93) and Hand Pulse Sensor Wires (97) to the
wires that come from the Computer (99) and then attach the Computer (99)
onto the top end of the Hand Pulse Handlebar (15) with four M5x10mm
Bolts (32) that were removed. Tighten bolts with the Hex Tool with Phillips
Screwdriver provided.
