Powerware
®
Plus 12 Operator's Manual (164200090 Rev E) !"!&$" "#)8
!' '&&"!
Press the Menu button to return to previous menu level. If you are not sure which
menu is currently displayed, press the Menu button repeatedly until the Main Menu
displays &&'%.
& '&&"!
Selects the currently displayed item shown on the second line of the LCD Display or
enters the next menu level. For example, if the display shows on the top
line and &$% on the second line, pressing the Select button enters the Meters
menu and shows the option.
# "$ "(! $$"( '&&"!%
Changes the cursor position within the menus, status screen, or event queue.
For example, if the display shows on the top line of the LCD Display
and &&'% on the second line, press the down arrow button to move to the
next menu item, &$%.
& "$ & $$"( '&&"!%
Shows possible device settings in menus and scrolls through the screen messages;
or moves the cursor position when entering the password or the date and time. For
example, if the LCD Display shows %%("$ on the top line and A
on the
second line, press the right arrow button to move the cursor one position to the right
A
.
See UPS Control Panel Functions" on page 15 for information on the Normal, Bypass,
Battery, and Overload indicators.
Using the Front Panel Display
You can use the front panel display to set up and monitor the UPS. The display has a
Main Menu and a System Setup Menu with several userĆselectable options.
The Main Menu
The Main Menu contains the following options:
1. UPS Status
2. Meters
3. Alarm Queue
4. Active Alarms
5. Battery Data
6. S. W. Versions
7. System Setup
Use the up and down arrow buttons to display the Main Menu options. Press the Select
button to enter one of the submenus.
