29
FIGURE 28
h) Re-install the belt cover.
i) Connect the wire to the spark plug.
4.16 Servicing the Wheels
:
Removing the Wheels
:
a) Stop the engine and wait for all moving parts to stop.
b) Disconnect the wire form the spark plug (Figure 3).
c) Remove the hardware as shown (Figure 29 & 30).
FRONT WHEEL ASSEMBLY REAR WHEEL ASSEMBLY
FIGURE 29 FIGURE 30
Assembling the Wheels
:
a) Re-install wheel assembly as shown in Figures 29 or 30.
b) Connect the wire to the spark plug.
5. STORAGE
5.1 Preparing the fuel system.
To prepare the lawn mower for off season storage, perform the recommended
maintenance procedures.
Store the lawn mower in a cool, clean, dry place. Cover the lawn mower to keep it clean
and protected.
