Exmark Metro HP - User Manual

Exmark Metro HP
44 pages
Save Page as PDF
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
Loading...
i
For Exmark Mower Parts Call 606-678-9623 or 606-561-4983
www.mymowerparts.com

Table of Contents

Other manuals for Exmark Metro HP

Preview: Parts Manual
Parts Manual16 pages

Questions and Answers

  • D
    Dana KingAug 1, 2025
    What to do if my Exmark Metro HP engine will not start?
    • C
      charles53Aug 1, 2025
      If your Exmark Lawn Mower engine won't start, try these steps: * Ensure the choke is in the correct position ('ON' for a cold engine, 'OFF' for a warm engine). * For B&S and 15 & 17 HP Kawasaki engines, check that the key switch is in the 'ON' position. * Confirm the transmission is in the 'true neutral' position. * Make sure the blades are disengaged and the blade switch is depressed. * Verify there's fuel in the tank and the fuel valve is open. * Check that the spark plug wire(s) are properly connected. * Inspect for loose or faulty wiring connections, disconnecting connectors carefully. * Look for and clean any corrosion at wiring connections with electrical contact cleaner, apply dielectric grease, and reconnect.
  • J
    Jacob HendersonAug 11, 2025
    Why is my Exmark Lawn Mower pulling left or right?
    • R
      ryanfisherAug 11, 2025
      If your Exmark Lawn Mower is pulling to the left or right, check the following: * Inspect idler arm pulleys and drive sheaves for any mud or grass buildup. * Ensure idler arms pivot freely; lubricate the pivots if they don't. * Check for worn drive belts. * Verify proper tire pressure in the drive tires (recommended: 12 to 16 psi). You might increase the pressure (up to 28 psi) in the tire on the side it's pulling towards.
  • C
    Colleen BakerAug 22, 2025
    How to fix an Exmark Metro HP Lawn Mower that cuts unevenly?
    • E
      Elizabeth FreyAug 22, 2025
      If your Exmark Lawn Mower cuts unevenly, you can try the following: * Check the drive tire pressure and tire circumference. * Ensure deck support pins have hairpin clips in the same hole position on each pin. * Verify deck support alignment and ensure all mounting bracket bolts are tight. * Check blade straightness from tip to tip (they should be within 3/16” of being in line).

Summary

Safety

Safety Alert Symbol

Explanation of the safety alert symbol and its associated hazard levels (Danger, Warning, Caution).

Operator Training and Preparation

Guidance on equipment understanding, safe operating practices, and personal protective equipment.

Operation Safety

Operation Safety Guidelines

Precautions for safe mower operation, including slopes, environment, and hazard avoidance.

Maintenance and Storage Safety

Maintenance and Storage Safety

Guidelines for safe maintenance procedures, storage, and fuel handling.

Attachments and Signs

Riding Attachments and Safety Signs

Instructions for using riding attachments and maintaining safety signs.

Specifications

Model, Engine, and Fuel System Specs

Details on model numbers, engine, fuel capacity, and safety interlock systems.

Controls, Transmission, and Drive System Specs

Information on steering, brakes, transmission, and wheel drive systems.

Tires, Deck, and Dimensions

Specifications for tires, deck cutting width, blade size, and machine dimensions.

Torque Requirements

Specified torque values for various bolts and fasteners on the mower.

Assembly Instructions

Handle and Fuel Tank Assembly

Step-by-step guide for assembling the handle, fuel tank, and related components.

Control Cable Hook-up

Connecting throttle and choke cables for different engine types.

Linkage Connections and Adjustments

Connecting blade engagement linkage and adjusting shifter/drive linkages.

Operation Instructions

Understanding Mower Controls

Explanation of operator presence controls, drive levers, and neutral lock/parking brake latches.

Pre-Start Procedures

Steps to take before starting the engine, including fueling and safety checks.

Starting and Stopping the Engine

Detailed procedures for starting and stopping the engine based on type and conditions.

Blade Engagement and Disengagement

Instructions for safely engaging and disengaging the mower blades.

Transporting the Mower

Safety guidelines and procedures for loading and transporting the mower.

Maintenance and Adjustments

Periodic Maintenance Checks

Routine checks including engine oil, air cooling, blades, and safety interlocks.

Lubrication and Fluid Changes

Schedules for lubrication, tire pressure, belt inspection, and oil changes.

Component Adjustments

Instructions for adjusting cutting height, anti-scalp rollers, linkages, and belt tensions.

Troubleshooting Common Issues

Mower Pulling or Uneven Cutting

Diagnosing and resolving issues related to mower pulling or uneven cutting.

Engine Starting Problems

Steps to troubleshoot and fix an engine that will not start.

Wiring Diagrams

B&S Vanguard and 14 HP Kawasaki Wiring

Electrical schematics for B&S Vanguard and 14 HP Kawasaki engine models.

Kohler and 15 & 17 HP Kawasaki Wiring

Electrical schematics for Kohler and 15 & 17 HP Kawasaki engine models.

Product Warranty Information

Limited Warranty Terms

Details on warranty coverage, duration, exclusions, and claim procedures.

Warranty Exclusions and Limitations

Specific conditions and actions that void the warranty or are not covered.

Exmark Metro HP Specifications

General IconGeneral
Fuel TypeGasoline
Deck TypeFabricated
TransmissionHydrostatic
CategoryWalk-Behind Lawn Mower
EngineKawasaki or Kohler
Cutting Height1.5" - 4.5"
