Exmark Metro HP - Tires, Deck, and Dimensions

- 9 -
2.7 WHEEL DRIVE SYSTEM:
Banded double A-Section V-Belts, single top side idlers and replaceable bolt-
on drive sheaves and brake drums.
2.8 TIRES
Drive Front Caster
Size16 x 6.50-8......9 x 3.50-4
Quantity............................. 2.........................................2
Tread................Turf Saver/Turf Master ..................Smooth
Ply Rating.......................... 4.........................................4
Pressure............... 14 psi(97 kPa).................. 22 psi(152 kPa)
2.9 Deck
2.9.1 Cutting Width:
Model 36 in....................35.25 in. (89.5 cm)
Model 48 in....................47.25 in. (120.0 cm)
Model 52 in....................52.00 in. (132.1 cm)
2.9.2 Discharge: Right Side
2.9.3 Blade Size:
Model 36 in....................18.00 in. (45.7 cm) ..............Qty. 2
Model 48 in....................16.25 in. (41.3 cm) ..............Qty. 3
Model 52 in....................18.00 in. (45.7 cm) ..............Qty. 3
2.9.4 Type of Drive: Manual engagement of belt with over-center lock. Belt tension
is adjustable via turnbuckle.
2.9.5 Deck Mounting: Full floating deck is attached to out-front support frame,
removable for service.
2.9.6 Cutting Height: Adjusts in 1/2” (.63 cm) increments from 1.5” (3.8 cm) to 4 1/2”
(11.4 cm).
2.10 DIMENSIONS
2.10.1 Overall Width:
36” 48” 52”
Discharge chute down
46.25” 58.25” 62.6”
(117.5 cm) (148.0 cm) (159.0 cm)
Discharge chute up
36.1” 48.1” 53.0”
(Transport only)
(91.7 cm) (122.2 cm) (134.62 cm)
2.10.2 Overall Length:
36” 48” 52”
Overall Length
77.7” 73.7” 75.9”
(197 cm) (187 cm) (193 cm)
2.10.3 Curb Weight:
36” 48” 52”
Curb Weight
∗
507 lbs. 555 lbs. 583 lbs.
(230 kg) (252 kg) (264 kg)
∗
Weights will vary slightly depending on engine option.
2.10.4 Overall Height: 42” (107 cm)(all units)
2.10.5 Tread Width (to outside of tires):
36” Model....................35.2” (89.4 cm)
48” Model....................35.2” (89.4 cm
52” Model....................35.2” (89.4 cm)
