Exmark Pioneer E Series - Specifications; Model Numbers; Systems

Specications
Specications
ModelNumbers
SerialNos:920,000andHigher
PNE22KA482;PNE24KA522
Systems
Engine
•EngineSpecications:SeeyourEngineOwner’s
Manual
•EngineOilType:Exmark4–CyclePremium
EngineOil
•RPM:FullSpeed:3600±50RPM(PTOnot
engaged)Idle:1500±100RPM
FuelSystem
•Capacity:7.0gal.(26.5L)
•TypeofFuel:Regularunleadedgasoline,87
octaneorhigher;containingnomorethan10%
methanolorethanol.
•FuelFilter:
Kawasaki:KawasakiP/N49019-7005
•FuelShut-OffValve:
AllUnits:1/4turnincrements(“ON”,“OFF”).
ElectricalSystem
•ChargingSystem:FlywheelAlternator
•ChargingCapacity:15amps
•BatteryType:BCIGroupU1
•RecommendedMinimumBatteryCCA:260CCA
•BatteryVoltage:12Volt
•Polarity:NegativeGround
•Fuses:
Allunits:
–25ampmainfuse
–25ampchargingsystemfuse
–10ampPTOfuse
–15ampaccessoryfuse
SafetyInterlockSystem
•PTOmustbedisengaged,brakeengaged,and
motioncontrolleversout(neutrallock)tostart
engine.(Itisnotnecessaryfortheoperatortobe
intheseattostarttheengine.)
•OperatormustbeinseatwhenPTOisengaged,
brakeisdisengaged,ormotioncontrolleversare
movedinorenginewillstop.
•Enginewillstopifeithertheleft,theright,or
bothleversaremovedfromneutrallockposition
whilebrakeisengaged.
OperatorControls
•SteeringandMotionControl:
Note:Motioncontrolleversareadjustableto
threeheights.
–Separatelevers,oneachsideoftheconsole,
controlspeedanddirectionoftravelofthe
respectivedrivewheels.
–Steeringiscontrolledbyvaryingtheposition
oftheleversrelativetoeachother.
–Movingmotioncontrolleversoutward(in
slots)locksthedrivesysteminneutral.
•PTOEngagementSwitch:Engageselectricclutch
(todrivebelt)whichengagesmowerblades.
•ParkingBrakeLever:Engagesparkingbrake.
•DeckHeightAdjustmentLever:Setscutting
heighttodesiredposition.
•DeckLiftPedal:Footpedalthatliftsdeck.
•TransportLock:Latchingposition:Automatically
latchesatthetransportposition.
Seat
•Type:Standardseatwithfoampaddedseat
cushionwitharmrestsandintegralsafetyswitch.
Optionalseat:Seatwithhighback,extra
widefoampaddedseatcushionwithinternal
suspension,thickbolstering,two-tonecover,
15
