Specications
Specications
Systems
Engine
•EngineSpecications:SeeyourEngineOwner’s
Manual
•EngineOilType:Exmark4–CyclePremium
EngineOil
•RPM:
–X-Series:FullSpeed:3750±50RPM(PTO
notengaged)Idle:1500±100RPM
–S-Series:FullSpeed:3600±50RPM(PTO
notengaged)Idle:1500±100RPM
–E-SerieswithExmarkEngines:FullSpeed:
3600±50RPM(PTOnotengaged)Idle:1500
±100RPM
–E-SerieswithKohlerEngines:FullSpeed:
3750±50RPM(PTOnotengaged)Idle:1500
±100RPM
FuelSystem
•Capacity:7.0gal.(26.5L)
•FuelRecommendations:
–Forbestresults,useonlyclean,fresh,unleaded
gasolinewithanoctaneratingof87orhigher
((R+M)/2ratingmethod).
–Oxygenatedfuelwithupto10%ethanolor
15%MTBEbyvolumeisacceptable.
–DoNotuseethanolblendsofgasoline(such
asE15orE85)withmorethan10%ethanol
byvolume.Performanceproblemsand/or
enginedamagemayresultwhichmaynotbe
coveredunderwarranty.
–DoNotusegasolinecontainingmethanol.
–DoNotstorefueleitherinthefueltankor
fuelcontainersoverthewinterunlessafuel
stabilizerisused.
–DoNotaddoiltogasoline.
•FuelFilter:ReplaceableIn-line
•FuelShut-OffValve:
AllUnits:1/4turn(“ON”,“OFF”).
ElectricalSystem
•ChargingSystem:FlywheelAlternator
•ChargingCapacity:15amps
•BatteryType:BCIGroupU1
•RecommendedMinimumBatteryCCA:260CCA
•BatteryVoltage:12Volt
•Polarity:NegativeGround
•Fuses:
Allunits:
–20ampchargingsystemfuse
(notusedonKohlerengines)
–15ampmainfuse
SafetyInterlockSystem
•LCDindicatorsappearforthePTO,parkbrake,
drivelevers,andoperatorpresenceinthemessage
displayontheRHcontrolpanel.
•PTOmustbedisengaged,brakeengaged,and
motioncontrolleversout(neutrallock)tostart
engine.(Itisnotnecessaryfortheoperatortobe
intheseattostarttheengine.)
•OperatormustbeinseatwhenPTOisengaged,
brakeisdisengaged,ormotioncontrolleversare
movedinorenginewillstop.
•Enginewillstopifeithertheleft,theright,or
bothleversaremovedfromneutrallockposition
whilebrakeisengaged.
OperatorControls
•SteeringandMotionControl:
Note:Motioncontrolleversareadjustableto
threeheights.
–Separatelevers,oneachsideoftheconsole,
controlspeedanddirectionoftravelofthe
respectivedrivewheels.
–Steeringiscontrolledbyvaryingtheposition
oftheleversrelativetoeachother.
–Movingmotioncontrolleversoutward(in
slots)locksthedrivesysteminneutral.
•PTOEngagementSwitch:Engageselectricclutch
(todrivebelt)whichengagesmowerblades.
•ParkingBrakeLever:Engagesparkingbrake.
•DeckHeightAdjustmentLever:Setscutting
heighttodesiredposition.
13

Exmark Radius RAE708GEM44300 Specifications

General

Engine Manufacturer	Exmark
Engine Displacement	708cc
Fuel Type	Gasoline
Cutting Width	44 inches
Transmission	Hydrostatic
Turning Radius	Zero-turn
Series	Radius
Engine Model	708cc
Deck Material	Steel
Cutting Height Range	1.5 - 4.5 inches
