36” MOWER DECK
3
Item Part No. Description Qty.
1 103-2312 Deck (103-2307-01) W/Decals
& Dogleg(36") ........................................1
2 1-302189-01 Wld, Dogleg Baffle ................................. 1
3 322-2 Screw, HH 5/16-18 x 5/8 ........................7
4 32128-20 Nut, Whizlock 5/16-18 ............................ 22
5 103-3600 Asm, Engagement Arm W/Bushings ...... 1
6 302-52 Zerk, 1/8 NPT Straight ...........................2
7 302-19 Zerk, 1/4-28 Str ......................................1
8 1-323385 Knob, Belt Cover....................................4
9 1-809020 Quick Pin, 10" Caster............................. 2
10 3296-29 Nut, Nyloc 5/16-18 .................................3
11 323-6 Screw, HH 3/8-16 x 1 .............................8
12 3290-357 Nut, Whizlock 3/8-16 ..............................16
13 1-323748 Ring, Push-On 7/16................................1
14 98-5975 Washer, Spring Disk 3/8......................... 9
15 1-808280 Pin, Clevis 5/16 x 1 ................................ 1
16 1-303105 Yoke ......................................................1
17 1-806003 Hairpin, Cotter #2................................... 2
18 32151-103 E-Ring....................................................1
19 702809 Screw, HH 3/8-16 x 1 7/8 ....................... 1
20 103-6584 Blade, Notched ......................................2
O
103-6582 Blade, Mulching ..................................... 2
103-6580 Blade, Low Lift ....................................... 2
103-1578 Blade, Solid............................................2
103-6337 Blade, Extreme ...................................... 2
21 1-513338 Washer, Special.....................................2
22 3253-7 Washer, Lock 1/2 ...................................2
23 3217-9 Nut, Hex 1/2-13...................................... 2
24 325-20 Screw, HH 1/2-13 x 6 .............................2
25 1-303352 Washer, Spindle..................................... 1
26 32120-35 E-Ring....................................................1
27 1-323735 Drive Belt (To Blades) ............................1
28X 1-803310 Setscrew, 5/16-18 x 3/8.......................... 2
29 322-6 Screw, HH 5/16-18 x 1 1/4 ..................... 9
30 3256-23 Washer, 5/16 SAE.................................. 1
31 1-303537 Stud, Belt Shield (Short)......................... 2
32 1-303536 Stud, Belt Shield (Long) .........................2
33 1-302218 Asm, Shield (1-302213-01) W/Decals .... 1
34 1-323417 Washer, Belt Cover Mount ..................... 4
35 1-322145-01 Wld, Caster Fork ....................................2
36 103-1236 Asm, Caster Wheel Assembly................2
37 1-302233-01 Chute .....................................................1
38 3296-56 Nut, Nyloc 1/4-20 Thin ........................... 1
39 1-323729 Bearing ..................................................2
40 323-4 Screw, HH 3/8-16 x 3/4 ..........................8
Item Part No. Description Qty.
41 1-603843 Pulley, Idler............................................ 1
42▲ 103-8387 Asm, Cutter Housing Complete.............. 2
43 322-5 Screw, HH 5/16-18 x 1.......................... 2
44 103-8280 Asm, Cutter Housing.............................. 2
45 302-61 Zerk, 45° 1/4-28..................................... 2
46 103-2535 Spacer ................................................... 2
47 1-403179 Tube, Pivot ............................................ 1
48 1-303314 Spacer, 10" Caster................................. 8
49 1-323529 Tube, Spindle ........................................ 2
50 321-4 Screw, HH 1/4-20 x 3/4.......................... 2
51 1-303514 Flange , Thrust Bearing ......................... 4
52 1-323339 Washer .................................................. 2
53 1-403183 Sheave, Blade Driven ............................ 2
54 3219-6 Nut, Hex 5/8-18 UNF ............................. 2
55 1-800861 Screw, HH 5/8-18 x 8............................ 2
56 1-807267 Key, 1/4 x 3/16 x 1 1/4 ........................... 2
57 1-323539 Spacer, Blade Drive............................... 8
58 1-513208 Washer, Spring Disc 5/8 ........................ 2
59 1-303434 Bushing, Engagement............................ 1
60 1-303348 Eye Bolt (Left Hand Thread) .................. 1
61 1-303236 Turnbuckle Body.................................... 1
62 1-303238 Eye Bolt (Right Hand Thread) ................ 1
63 1-322235 Arm, Assist ............................................ 1
64 322-10 Screw, HH 5/16-18 x 2........................... 1
65 1-323174 Linkage, Assist Arm ............................... 1
66 103-2281 Asm, Caster/Mnt Complete, Weighted ... 2
67 103-2296 Asm, Caster Wheel Support
W/Bearings, Weighted ........................... 2
68 103-2297-01 Wld, Caster Wheel Support, Weighted... 2
69 1-303334 Washer, Spring Disc 5/16 ..................... 9
70 1-324372 Asm, Pad/Spring.................................... 1
71 103-1330 Guard, Bearing Top ............................... 2
72 3256-3 Washer, 5/16 Std................................... 1
73 1-323715 Rod, Brake 36" ...................................... 1
74 1-323071 Spring .................................................... 1
75 1-323747 Spring, Compression ............................. 1
76 1-323746 Spacer, Flanged .................................... 1
77 3296-42 Nut, Nyloc 1/4-20................................... 2
78 1-513547 Spacer, Front Caster.............................. 2
79 103-2171 Kit, Tire & Wheel Asm W/ Spacer .......... 2
80 1-513809 Roller Bearing........................................ 1
81 1-513810 Bushing ................................................. 4
82 3219-2 Nut, Hex 5/16-24.................................... 1
83 3272-5 Pin, Cotter 3/32 x 1/2 ............................. 1
Exmark red touch up paint (spray paint - P/N 1-850337 - .6 oz liquid bottle - P/N 103-9140).
X Use Pro-lock Nut Type (p/n 1-840022 .5 ml tube) on the setscrews.
O Requires installation of Micro-Mulch accessory for proper mulching. Mulch kit P/N MK362(36”)
Apply Mobil HTS grease (P/N 103-5217 1.5 oz packet) (or a food-grade anti-seize) between the spindles & bearings and spindles
& sheaves and under top bearing guard. DO NOT use a copper or nickel based anti-seize.
▲ Does not include items #4, #29, & #69.
