1. Potentiometer Calibration
Holding button K1 & K5 while powering on -- Start "beep-beep-beep" meaning it is
calibrating -- After beeping, holding K2 & K6 to exit calibration -- There will be "beep-
beep" / "beep" based on left throttle mode / right throttle mode.
2. Turbo Switch
Holding OK & K4 & K8 while powering on -- on as 20dbm.
Holding OK & K3 & K7 while powering on -- off as 14dbm.
3. Logo on/off
Holding BACK & UP while powering on -- Display / hide EXMITTER logo.
4. Mode1 / Mode 2 Switch
Holding OK & DOWN & K6 while powering on -- Saved as Mode 2(left throttle).
It comes with "beep--beep" sound when setting as mode 2.
Holding OK & DOWN & K2 while powering on -- Saved as Mode 1(right throttle).
It comes with "beep--" sound when setting as mode 1.
After switch setting of mode 1 / mode 2, you also need to switch the sticks mechanically
following below steps.
Screw #1
Screw #2
Screw #3
Screw #4
Limit Plate
Screw #5
Screw #6
Spring Plate
Screw #7
Screw #8
To Next Page
