Screw #1
Screw #2
Spring Plate
Limit Plate
Screw #7
Screw #8
Screw #3
Screw #4
1. Loosen screws on back plate and remove the back plate.
2. Loosen screws #1 - #8.
3. Loosen spring plate and limit plate, place them in the other ends as shown in picture,
with 180 degrees rotation.
4. Tighten spring plate and limit plate. The screws tightness decide the feeling of
hangdling throttle stick and elevator stick.
5. Tighten screws #1 - #8.
6. Assemble the back plate and tighten by screws.
NOTICE: The mode 1/2 mechanical swich is using mode 1 swiched to mode 2 as
example instruction. To switch from mode 2 to mode 1, just reverse the order of spring
plate and limit plate.
Perform Range Check
FHSS Radio Control System
FHSS is an advanced radio control system with better performance of anti-interference.
EX6 comes with FHSS system, its faster frequence prevents interference signal from
catching up. Therefore using this system allows the radio to work in a more stable
environment.
