Display have 4 main elements:
- ExoCrutch charge indicator.
- Exoskeleton charge indicator.
- Exoskeleton current condition indicator.
- Selected motion/mode.
Figure 81
8.2. ExoCrutch available motions:
Icon
Value
Not
defined
pose
Pose reset to sitting pose
Pose reset to standing pose
Sitting
pose
Standing up (Low)
Standing up (Middle)
Standing up (High)
Standing
pose
Sitting down
