2 Your safety is important to us
GB
39
Pedestal adapter and
pedestal type
Wall arm type and
mounting elements
Special mounting elements
The Hood dryer, model M41 may only be mounted
using the pedestal adapter STA1
ST3/ST5 and
the pedestal tube
type ST3 / ST5 and the
pedestal base
type ST3 / ST5.
The Hood dryer, model M41 may only be mounted
on the wall arm
type WA04/75
D The wall arm
may only be mounted on a wall
bracket
type WL04 that has been installed as
described in the currently valid mounting
instructions.
The Hood dryer, model M41 can also meet
individual installation requirements using diverse
special mounting elements. Please refer to the
currently applicable Operating Manual of the
appropriate wall extension for operation
procedures pertaining to these models.
