20
English
Full color “Per Key” LED Keyboard
Click LED Keyboard in the Control Center to access
the LED Keyboard application.
Figure 14 - LED Keyboard Application (Full color “Per
Key” LED Keyboard)
LED Mode - Keyboard
Click Keyboard, on the left under LED Mode, to set in-
dividual color settings for any keyboard keys you may
wish to highlight.
Simply click to highlight any keys to which you wish to
apply the color, and then click a color from the color
swatch to apply the color. To highlight further keys first
click to deselect any previously selected keys, then repeat
the above procedure. To clear settings click Restore.
LED Mode - Keyboard Effect
Click on Keyboard Effect (under LED Mode) and then
click any of the Effect buttons to view the effects on the
keyboard. You can also adjust the LED Speed for the ef-
fects from the buttons on the right. Some effect colors can
set to Random or Custom.
Table 5 - Keyboard Effects (Full color “Per Key” LED Key-
board)
KB Sleep Timer
Enable and then select the amount of time for which the
system is idle before the keyboard LED enters sleep mode
(i.e. the LED keyboard illumination will turn off to save
power).
KB Brightness
You can adjust the keyboard brightness using the Bright-
ness slider.
On boot the key-
board will mo-
mentarily flash.
You can click in
the Override
Boot Effect
check box to
disable the key-
board flashing
effect as the
system boots.
Wave Breath
Scan Blink
Random Ripple
Snake
PC 5070 DDDFDN book v2.book Page 20 Thursday, July 30, 2020 4:29 PM
