Exor eX710 User Manual

11
MANUGENEX7xx
Operating Instructions
VER 2.00
4 Technical Data
Technical Data
Model eX705 eX707
Display / Backlight TFT Color / LED TFT Color / LED
Colors 64K 16M
Resolution 800X480 800X480
Diagonal (inches) 5” widescreen 7” widescreen
Dimming yes yes
Flash 4GB 4GB
SD card slot yes yes
RAM 512MB 1GB
Serial Port
RS-232,RS-485, RS-422
software congurable
RS-232,RS-485, RS-422
software congurable
Ethernet port 2 10/100Mb 2 10/100Mb, 1 10/100/1000Mb
USB port
1 Host interface version 2.0
max. 500mA
2 Host interface version 2.0
max. 500mA
Expansion slot 1 Optional Plugin 2 Optional Plugin
Battery rechargeable rechargeable
Real Time Clock yes yes
Voltage
24Vdc (
*) 24Vdc (*)
Current rating (at 24VDC) 0.6A 0.7A
Weight 1 Kg 1.3 Kg
(
*) 10-32Vdc
For applications requiring compliance with EN 61131-2 and specically in reference to 10 ms voltage dips, the
power supply range voltage is 18-32Vdc.

Exor eX710 Specifications

General

Brand	Exor
Model	eX710
Category	Touch Panel
Language	English
