5 6
Assembly Instructions
Do Not Return To Place Of Purchase
1
3
Attach Leg Brace and Long Legs
2
Please have your owner’s manual and model number available
for reference.
For Easiest Assembly:
1. Select an area where you will assemble this product. To
protect components, choose a smooth surface that’s free
of cracks or openings.
2. Spread out all parts.
3. Tighten all hardware connections by hand first. Then,
before completing each step, go back and fully tighten
all hardware. Be careful not to overtighten. That could
damage surfaces or strip threads.
4. For best results, complete each step in the order
presented.
To complete assembly you will need:
• One bag of charcoal (not included)
Typical assembly is approximately 45 minutes.
W CAUTION: Two (2) people are required for assembly.
Attach Bottom Shelf
4
Attach Leg Brace and Short Legs
3
3
Short Legs
Long Legs
D
E
D
x 4
E
x 4
D
x 4
D
1
2
To Next Page
