Expert EX-9132C-2 - Top Side Panel Details; Right Side Panel Details; Serial I;O Port Connectivity

10
2
2
EX-9132C-2 Description & Installation
Product Panel Views
Top Side
Right Side
Serial I/O Port of RS-232 and RS-232/422/485
Connect the serial data cable between the converter device and the serial devices.
Follow the parameter setup procedures to configure the converter (see the following
chapters).
DC-In
Power Outlet
Ethernet LAN Port
Serial I/O Port
RS-232
Serial I/O Port
RS-232/485/RS-422
LED Indicators
Reset Button
RS-232
RS-232/485/422
