6 DL150-en-US_V2.7 6/22
Specifications
Display Multi-function LCD
Maximum data points 100,000
Channels Single channel, TRMS AC Voltage or Current
Sample rate 1s to 24h selectable
Transient capture >0.244mS
Data output USB port
Open input indication "LO" appears on the LCD
Low battery indication Empty battery symbol appears on the LCD
Power supply 4 AAA Batteries
Battery life 5 days (approximately)
AC Adaptor 9V, 0.5A
Standards
CAT III 600V
Operating Temperature 32 to 122°F, 0 to 50°C
Operating Humidity <70% RH
Current Clamp Jaw opening 0.5” (12.7mm)
Dimensions 4.5 x 2.5 x 1.3” (114 x 63 x 34mm)
Weight 8.7oz. (248g)
Range Accuracy
Voltage
40Hz to 1kHz
10VAC to 600.0VAC ±2.0%±1V
Current
50/60Hz
10A to 200.0A ±2.0%±1A
Peak Measurement 8.0 to 850.0V ±5.0%
