Extech Instruments EMF450 Quick Start

Quick Start (en)
Introduction
This meter simultaneously measures and displays magnetic field,
electrical field, and RF strength, expressed in units of electrical and
magnetic field strength and power density.
Safety
• The field strength near radiators increases proportionally to the
inverse cube of the distance.
• Field strength meters can underrate pulsed signals, particularly
with radar signals.
• For indoor use; pollution level 2.
CAUTION
• Use caution near powerful radiation sources.
• Do not operate near combustible gases or in damp environments.
Meter Description
1. 61 mm (2.4 in.) colour TFT
display
2. Select & Down button
3. Power & Menu button
4. Hold & Enter button
5. Battery compartment & informa-
tion chart on back
6. RF historical records (20 groups)
#NAS100173; r. AC/94338/94343; en-US
1

Extech Instruments EMF450 Specifications

General

Sensor Type	LF - Magnetic Fields, LF- Electric Field Sensor, RF Strength
Range	20mG /200mG /2000mG, 2µT /20µT /200µT, 50V/m to 2000V/m, 0.02µW/m² to 554.6mW/m²
Display resolution	0.02/0.1/1, 1V/m, 0.02µW/m², 0.2µA/m, 0.2mV/m, 0.002µW/cm², 2dB
Frequency range	50/60Hz, 50/60Hz, 50MHz to 3.5GHz
Accuracy	± (15% + 100 digits), ± (7% + 50 digits), ± 2dB at 2.45GHz
Display	4 digits Triple color TFT display
Sample rate	6 seconds
Sensors	Triple axes (XYZ) ELF and RF and Electric field sensor
Battery	Three (3) 1.5V alkaline batteries
Battery Life	Approx. 8 hours
Operating temperature and RH%	5°C~40°C (41°F ~104°F); < 80%RH
Storage temperature and RH%	-10°C to 60°C (14°F ~140°F); < 70%RH

Weight and Dimensions

Weight	Approx. 120g (4.2 oz.)
Dimensions	115 x 60 x 21mm (4.5 x 2.4 x 0.08”)
