EX505-en-GB_v7.3 8/15
14
Function Range Resolution Accuracy
Resistance
400 0.1 (1.2% reading + 4 digits)
4k 0.001k (1.0% reading + 2 digits)
40k 0.01k
(1.2% reading + 2 digits)
400k 0.1k
4M 0.001M
40M 0.01M (2.0% reading + 3 digits)
Capacitance 4nF 0.001nF
(5.0% reading + 0.5nF)
40nF 0.01nF
(5.0% reading + 7 digits)
400nF 0.1nF
(3.0% reading + 5 digits)
4F 0.001F
40F 0.01F
100F 0.1F (5% reading + 5 digits)
Frequency 5.999Hz 0.001Hz
(1.5% reading + 1 digits)
59.99Hz 0.01Hz
599.9Hz 0.1Hz
(1.2% reading + 3 digits)
5.999kHz 0.001kHz
59.99kHz 0.01kHz
599.9kHz 0.1kHz
5.999MHz 0.001MHz
(1.5% reading + 4 digits)
9.999mHz 0.001MHz
Sensitivity: 0.5V rms <500kHz; 3V rms >500kHz
Duty Cycle 0.1 to 99.9% 0.1%
(1.2% reading + 2 digits)
Pulse width: 100µs to 100ms, Frequency: 5Hz to 150kHz
Temp
(type-K)
-4 to 1382F
0.1<400
1 ≥ 400
(3.0% reading + 5C /9F)
(probe accuracy not included)
-20 to 750C
Note: Accuracy specifications consist of two elements:
(% reading) – This is the accuracy of the measurement circuit.
(+ digits) – This is the accuracy of the analog to digital converter.
