Extech Instruments EX505-K User Manual

EX505-en-GB_v7.3 8/15
13
Specifications
Function Range Resolution Accuracy
DC Voltage 400mV 0.1mV
(0.5% reading + 2 digits)
4V 0.001V
(1.2% reading + 2 digits)
40V 0.01V
400V 0.1V
1000V 1V
(1.5% reading + 10 digits)
AC Voltage 400mV 0.1mV
(2.0% reading + 10 digits)
4V 0.001V
(2.0% reading + 5 digits)
40V 0.01V
400V 0.1V
1000V 1V
(2.5% reading + 5 digits)
DC Current
400A 0.1A (1.0% reading + 3 digits)
4000A 1A
(1.5% reading + 3 digits)
40mA 0.01mA
400mA 0.1mA
10A 0.01A
(2.5% reading + 5 digits)
AC Current
400A 0.1A (2.5% reading + 10 digits)
4000A 1A
(2.5% reading + 5 digits)
40mA 0.01mA
400mA 0.1mA
10A 0.01A
(3.0% reading + 7 digits)
NOTE: Accuracy is stated at 18
o
C to 28
o
C (65
o
F to 83
o
F) and less than 75% RH.
