EX505-EU-EN-V7.0-12/11

Introduction

Congratulations on your purchase of the Extech EX505 True RMS Autoranging Multimeter. This meter

measures AC/DC Voltage, AC/DC Current, Resistance, Capacitance, Frequency, Diode Test, and

Continuity plus Thermocouple Temperature. It features a waterproof, rugged design for heavy duty use

This meter is shipped fully tested and calibrated and, with proper use, will provide years of reliable

service.

Safety

This symbol adjacent to another symbol, terminal or operating device indicates

that the operator must refer to an explanation in the Operating Instructions to

avoid personal injury or damage to the meter.

This WARNING symbol indicates a potentially hazardous situation, which if not

avoided, could result in death or serious injury.

This CAUTION symbol indicates a potentially hazardous situation, which if not

avoided, may result damage to the product.

This symbol advises the user that the terminal(s) so marked must not be

connected to a circuit point at which the voltage with respect to earth ground

exceeds (in this case) 1000 VAC or VDC.

This symbol adjacent to one or more terminals identifies them as being associated

with ranges that may, in normal use, be subjected to particularly hazardous

voltages. For maximum safety, the meter and its test leads should not be handled

when these terminals are energized.

This symbol indicates that a device is protected throughout by double insulation or

reinforced insulation.

PER IEC1010 OVERVOLTAGE INSTALLATION CATEGORY

OVERVOLTAGE CATEGORY I

Equipment of OVERVOLTAGE CATEGORY I is equipment for connection to circuits in which

measures are taken to limit the transient overvoltages to an appropriate low level.

Note – Examples include protected electronic circuits.

OVERVOLTAGE CATEGORY II

Equipment of OVERVOLTAGE CATEGORY II is energy-consuming equipment to be supplied from

the fixed installation.

Note – Examples include household, office, and laboratory appliances.

OVERVOLTAGE CATEGORY III

Equipment of OVERVOLTAGE CATEGORY III is equipment in fixed installations.

Note – Examples include switches in the fixed installation and some equipment for industrial use with

permanent connection to the fixed installation.

OVERVOLTAGE CATEGORY IV

Equipment of OVERVOLTAGE CATEGORY IV is for use at the origin of the installation.

Note – Examples include electricity meters and primary over-current protection equipment

WARNING

CAUTION

MAX

1000V

Need help?

Do you have a question about the Extech Instruments EX505 and is the answer not in the manual?

Extech Instruments EX505 Specifications

General

Type	Digital Multimeter
Max Current Measurement	10A
Resistance Measurement	Yes
Resistance Range	600Ω, 6kΩ, 60kΩ, 600kΩ, 6MΩ, 60MΩ
Capacitance Measurement	Yes
Frequency Measurement	Yes
Temperature Measurement (Type K)	Yes
Data Hold	Yes
Backlight	Yes
Auto Ranging	Yes
Relative Mode	Yes
Waterproof	No
Safety Category	CAT III 600V
Battery Type	9V
Continuity	Yes
Diode Test	Yes
Duty Cycle	Yes
Max Voltage Measurement	600V
Current Range (AC)	600μA, 6000μA, 60mA, 600mA, 10A
Current Range (DC)	600μA, 6000μA, 60mA, 600mA, 10A
Temperature Range	-40°C to 1000°C
