EX530 V3.3 4/29/07
14
Specifications
Function Range Resolution Accuracy
400mV 0.01mV
4V 0.0001V
40V 0.001V
400V 0.01V
±(0.06% reading + 2 digits)
DC Voltage
1000V 0.1V
±(0.1% reading + 2 digits)
50 to 1000Hz
400mV 0.01mV
±(1.0% reading + 4 digits)
4V 0.0001V
40V 0.001V
400V 0.01V
AC Voltage
1000V 0.1V
±(1.0% reading + 3 digits)
All AC voltage ranges are specified from 5% of range to 100% of range
400µA 0.01µA
4000µA 0.1µA
40mA 0.001mA
400mA 0.01mA
10A 0.001A
±(1.0% reading + 3 digits)
DC Current
(20A: 30 sec max with reduced accuracy)
50 to 1000Hz
400µA 0.01µA
4000µA 0.1µA
40mA 0.001mA
400mA 0.01mA
10A
0.001A
±(1.5% reading + 3 digits)
(20A: 30 sec max with reduced accuracy)
AC Current
All AC voltage ranges are specified from 5% of range to 100% of range
NOTE: Accuracy is stated at 65
o
F to 83
o
F (18
o
C to 28
o
C) and less than 75% RH.
To Next Page
