ACCurrentMeasurements
WARNING:Donothandlethemeterabovethefinger/handguardbarrier.
CAUTION:ObserveCATIII600VwithrespecttoEarthGroundfortheJaw.
1. Pressthe‘A’buttontoaccesstheACCurrentmeasurementmode.TheAsymbolwillappear
onthedisplayinthelowerrighthandsideindicatingAmperes(Amps).
2. Pressthejawtriggertoopentheclampjaw.
3. Positiontheclamparoundonlyoneconductor.Seeaccompanyingdiagramsfor
correctand
incorrectuse.
4. Readthecurrentinthedisplay.Thedisplaywillindicatetheproperdecimalpointandvalue.





