Extech Instruments MA1500 User Guide

MA1500 -EU-EN-V1.2-4/11
10
Specifications
Function Range& Resolution Accuracy (% of reading)
400.00 ADC ± (2.0% +30digits) DC Current
1500.0 ADC ± (2.5% +30digits)
400.00 AAC
1500.0 AAC
± (2.8% +30digits)
AC Current
True RMS (50Hz to 60
Hz)
All AC current ranges are specified from 5% to 100% of range
400.00 mVDC ± (0.1% + 5 digits)
4.0000 VDC
40.000 VDC
400. 00 VDC
± (0.1% + 4 digits)
DC Voltage
1000.0 VDC ± (0.5% + 4 digits)
400.00 mVAC ± (0.8% + 40 digits)(50/60Hz)
4.0000 VAC
40.000 VAC
400. 00 VAC
750.0 VAC
± (1.0% + 30 digits)
AC Voltage
True RMS (50 Hz to
1000 Hz)
All AC voltage ranges are specified from 5% to 100% of range
400.00 Ω ± (0.5% + 9 digits)
4.0000 kΩ
40.000 kΩ
400.00 kΩ
± (1.0% + 4 digits)
4.0000 MΩ ± (2.0% + 10 digits)
Resistance
40.000 MΩ ± (3.0% + 10 digits)
400.00 nF
±(3.5% reading + 40 digits)
4000.0 nF
40.00.μF
400.0.μF
±(3.5% reading + 10 digits)
4.000 mF
20.00 mF
±(5% reading + 10 digits)
Capacitance
40.00 mF Not specified
40.000 Hz
400.00 Hz
4.0000 kHz
40.000 kHz
400.00 kHz
4.0000MHz
40.000MHz
±(0.3% reading + 2 digits)
Frequency
Sensitivity: 0.8V rms min. @ 20% to 80% duty cycle and <100kHz; 5Vrms min @ 20% to 80%
duty cycle and > 100kHz.
10.0 to 95.0%
± (1.0% reading + 2 digits)
Duty Cycle
Pulse width: 100µs - 100ms, Frequency: 10Hz to 100kHz
-100.0 to 1000.0°C ±(1.0% reading + 2.5 °C)
-148.0 to 1832.0°F ±(1.0% reading + 4.5°F)
Temp
(type-K)
(probe accuracy not included)
