Extech Instruments MA1500 User Manual

MA1500-en-GB_v1.4 10/18
11
Specifications
Function
Range& Resolution
Accuracy (% of reading)
DC Current
400.00 ADC
± (2.0% +30digits)
1500.0 ADC
± (2.5% +30digits)
AC Current
True RMS (50Hz to 60
Hz)
400.00 AAC
± (2.8% +30digits)
1500.0 AAC
All AC current ranges are specified from 5% to 100% of range
DC Voltage
400.00 mVDC
± (0.1% + 5 digits)
4.0000 VDC
± (0.1% + 4 digits)
40.000 VDC
400. 00 VDC
1000.0 VDC
± (0.5% + 4 digits)
AC Voltage
True RMS (50 Hz to
1000 Hz)
400.00 mVAC
± (0.8% + 40 digits)(50/60Hz)
4.0000 VAC
± (1.0% + 30 digits)
40.000 VAC
400. 00 VAC
750.0 VAC
All AC voltage ranges are specified from 5% to 100% of range
Resistance
400.00 Ω
± (0.5% + 9 digits)
4.0000 kΩ
± (1.0% + 4 digits)
40.000 kΩ
400.00 kΩ
4.0000 MΩ
± (2.0% + 10 digits)
40.000 MΩ
± (3.0% + 10 digits)
Capacitance
400.00 nF
(3.5% reading + 40 digits)
4000.0 nF
(3.5% reading + 10 digits)
40.00.μF
400.0.μF
4.000 mF
(5% reading + 10 digits)
20.00 mF
40.00 mF
Not specified
Frequency
40.000 Hz
(0.3% reading + 2 digits)
400.00 Hz
4.0000 kHz
40.000 kHz
400.00 kHz
4.0000MHz
40.000MHz
Sensitivity: 0.8V rms min. @ 20% to 80% duty cycle and <100kHz; 5Vrms min @ 20% to 80%
duty cycle and > 100kHz.
Duty Cycle
10.0 to 95.0%
 (1.0% reading + 2 digits)
Pulse width: 100µs - 100ms, Frequency: 10Hz to 100kHz
Temp
(type-K)
-100.0 to 1000.0C
(1.0% reading + 2.5 C)
-148.0 to 1832.0F
(1.0% reading + 4.5F)
(probe accuracy not included)
