Extech Instruments MiniTec Series

3 MN24-en-US_V2.2 07/15
1
2
3
4
5
Description
1. LCD Display
2. Function switch
3. COM jack
4. 10A jack
5. Positive jack
Note: Tilt stand, fuse, and battery compartment are located on the rear of the unit
Symbols
•))) Continuity
Diode test
 micro (amps)
m milli ( volts, amps)
k kilo (ohms)
 ohms
VDC volts direct current
VAC volts alternating current
ADC amps direct current
BAT Low battery
