Extech Instruments SDL350 User Manual

9 SDL350-en-GB_V1.5 6/16
Set the Temperature Units of Measure (°C or °F)
1. Access the t-CF parameter.
2. Use the arrow keys to select °C or °F.
3. Press ENTER to confirm setting.
4. Press and hold the SET key for at least 1.5 seconds to exit to the normal operation mode (or
simply wait 7 seconds for the meter to automatically switch to the normal operating mode).
Set the Temperature Thermocouple Type (J or K)
1. Access the tYPE parameter.
2. Use the arrow keys to select J or K.
3. Press ENTER to confirm setting.
4. Press and hold the SET key for at least 1.5 seconds to exit to the normal operation mode (or
simply wait 7 seconds for the meter to automatically switch to the normal operating mode).
Set the Air Flow Volume measurement units to CFM (F-US) or CMM (F-EU)
1. Access the SET F-US / F-EU parameter.
2. Use the arrow keys to select US or EU. US represents CFM (cubic feet per minute) and EU
represents CMM (cubic meters per minute)
3. Press ENTER to confirm setting.
4. Press and hold the SET key for at least 1.5 seconds to exit to the normal operation mode (or
simply wait 7 seconds for the meter to automatically switch to the normal operating mode).
Set the Area value for the air duct under test (for Air Flow Volume measurements only)
1. Access the ArEA parameter.
2. Use the arrow keys set the area of the duct (the equation L * W is used for rectangular ducts;
3.14 * R
2
is used for circular ducts). Note that the value must be set in square feet or square
meters; therefore if the measurement is made in square inches, the area value must be
converted to square feet. The setting range is 0.01 to 322.93.
3. Press ENTER to confirm setting.
4. Press and hold the SET key for at least 1.5 seconds to exit to the normal operation mode (or
simply wait 7 seconds for the meter to automatically switch to the normal operating mode).
Battery Replacement and Disposal
When the low battery icon appears on the LCD, the batteries must be replaced. Several hours
of accurate readings are still possible in this condition; however batteries should be replaced as
soon as possible:
1. Remove the two (2) Phillips screws from the rear of the meter (directly above the top of the tilt
stand).
2. Remove and safely place the battery compartment and screws where they will not be damaged
or lost.
3. Replace the six (6) 1.5V ‘AA’ batteries observing polarity.
4. Replace the battery compartment cover with the two (2) Phillips screws.
All EU users are legally bound by the Battery Ordinance to return all used batteries to
community collection points or wherever batteries / accumulators are sold!
Disposal in household trash or refuse is prohibited!
Disposal: Follow the valid legal stipulations in respect of the disposal of the device at the
end of its lifecycle
Other Battery Safety Reminders
 Never dispose of batteries in a fire. Batteries may explode or leak.
 Never mix battery types. Always install new batteries of the same type.

Extech Instruments SDL350 Specifications

General

Model	SDL350
Category	Multimeter
Brand	Extech Instruments
Display Type	LCD
Max Voltage Measurement	1000V
Max Current Measurement	10A
Data Logging	Yes
Diode Test	Yes
Continuity Test	Yes
Data Hold	Yes
Auto Power Off	Yes
Frequency Measurement	10MHz
Temperature Measurement	-40°C to 1000°C
DC Voltage Range	1000V
AC Voltage Range	750V
DC Current Range	10A
AC Current Range	10A
Resistance Range	40MΩ
Capacitance Range	100µF
Frequency Range	10MHz
Safety Rating	CAT III 1000V
