Extech Instruments TG20 User Manual

TG20-EU-EN-V1.0 03/12
3
Identifying telephone cable Tip and Ring – Using Alligator Clips
1. Switch the transmitter to the OFF position
2. Connect the BLACK clip to ground
3. Connect the RED clip to a line.
4. The LED color identifies the line.
5. GREEN indicates the Ring line, RED indicates the Tip line.
6. If both RED and GREEN light up, AC voltage is present (do not exceed 24V)
Identifying telephone cable Line Condition
1. Switch the transmitter to the OFF position
2. Plug the connector into the phone line or connect the RED clip to the RING line and the
BLACK clip to the TIP line.
3. The LED color identifies the line condition.
a. GREEN indicates a clear line.
b. RED indicates a busy line.
c. Green with a flashing RED indicates a ringing line.
Battery replacement
Open the battery cover and replace the battery as needed.
You, as the end user, are legally bound (Battery ordinance) to return all used batteries
and accumulators; disposal in the household garbage is prohibited!
You can hand over your used batteries / accumulators at collection points in your
community or wherever batteries / accumulators are sold!
Disposal: Follow the valid legal stipulations in respect of the disposal of the device at the
end of its lifecycle
Specifications
Power 9V battery (1 for transmitter and 1 for probe))
Dimensions Probe - 8.7x2x1.3" (220x50x32mm)
Transmitter - 2.6x2.7x1.1" (65x68x28mm)
Weight Probe 3.2oz (91g);
Transmitter3.2oz (91g)
