CHAPTER 24
PAGE 9
EXT
RA - FLUGZEUGBAU GmbH
SERVICE MANUAL EXTRA 200
PAGE DATE: 1. July 1996
24-61-00 MAINTENANCE PRACTICES
I M P O R T A N T If replacement of wiring passing the firewall is neces-
sary, renew the sealing of the bushing grooves and gaps
at the engine side of the firewall. Use PRC-812 (Prod-
ucts Research & Chemical Corporation, USA) firewall
sealant.
24-61-01 Combined Switch and Circuit Breaker
Removal/Installation
C A U T I O N Disconnect battery
1 Remove the instrument panel cover per Ch. 31.
2 Disconnect the tubings from the resp. instruments.
3 Remove the instrument panel attachment screws.
4 Turn down the panel.
5 Loosen the bus bar attachment screws and remove bus
bar if necessary.
6 Disconnect wiring.
7 Remove the attachment nut at the front side of the in-
strument panel.
8 Remove the combined switch and circuit breaker.
9 Install in reverse sequence of removal.
