CHAPTER 24
PAGE 10
EXT
RA - FLUGZEUGBAU GmbH
SERVICE MANUAL EXTRA 200
PAGE DATE: 1. July 1996
24-61-02 Lever Switch
Removal/Installation
C A U T I O N Disconnect battery
1 Remove the instrument panel cover per Ch. 31.
2 Disconnect the tubings from the resp. instruments.
3 Remove the instrument panel attachment screws.
4 Turn down the panel.
5 Disconnect wiring.
6 Remove the attachment nut at the front side of the in-
strument panel.
7 Remove the combined switch and circuit breaker.
8 Install in reverse sequence of removal.
24-61-03 Subminiature Pushbotton Switch
Removal/Installation
C A U T I O N Disconnect battery
1 Remove the attachment nut.
2 Tie out the switch some centimeters.
3 Loosen the soldered connections.
4 Remove the switch.
5 Install in reverse sequence of removal
MAINTENANCE PRACTICES
