CHAPTER 25
PAGE 3
EXT
RA - FLUGZEUGBAU GmbH
SERVICE MANUAL EXTRA 200
PAGE DATE: 1. July 1996
25-10-00 FLIGHT COMPARTMENTS
The EXTRA 200 is standard equipped with a pilot and a co-
pilot seat including special aerobatic seat belt / shoulder
harnesses for both seats. An aircraft document bag is
installed in the rear cockpit.
25-10-01 Front Seat
The front seat is a nonadjustable one-piece composite
design. It is connected to the fuselage by four screws at the
top of the backrest and by two screws at the buttom of the
seat.
25-10-02 Rear Seat
The rear seat assembly consists of two composite parts. The
backrest is connected to the seat and to the fuselage by
means of quickpins. Multihole tubes allow adjustment. Up
to Ser. No. 9 the seat is connected to the fuselage by bolts.
From Ser. No. 10 the seat is in front attached to the steel tube
by bolts and in the rear via a multihole rod and quickpins
allowing adjustment of height.
25-10-03 Seat Belts
(Refer to Figure 1) Each seat is equipped with a special
aerobatic seat belt / shoulder harnesses from the manufac-
turer "Hooker custom Harness". Such an assembly of straps
consists of a right and left shoulder harness, two right and
two left seat belts and a crotch strap.
PAGE DATE: 15. December 1999
