CHAPTER 27
PAGE 19
EXT
RA - FLUGZEUGBAU GmbH
SERVICE MANUAL EXTRA 200
PAGE DATE: 1. July 1996
27-21-00 MAINTENANCE PRACTICES
I M P O R T A N T Perform checks 10-11 of "Flight Controls" presented in
Chapter 05-20-04 after each maintenance work affect-
ing the rudder control cables.
27-21-01 Rudder Removal/Installation
1 Disconnect the rudder control cables from the bottom
hinge bellcrank.
2 Loosen the hinge bolts and the ground bonding leads
and remove the bolts.
3 Install in reverse sequence of removal. Observe the sec-
ond Note of Chapter 27-01-00.
27-21-02 Bottom Hinge Bracket Removal/Installation
1 Remove the rudder per Chapter 27-21-01.
2 Loosen the attachment bolts.
3 Remove the bottom hinge bracket with the travel stop
plate.
4 Install in reverse sequence of removal.
27-21-03 Bottom Hinge Bellcranks Removal/
Installation
1 Remove the rudder per Chapter 27-21-01.
2 Loosen the attachment bolts.
3 Remove the bottom hinge bellcranks.
4 Install in reverse sequence of removal.
