CHAPTER 27
PAGE 22
EXT
RA - FLUGZEUGBAU GmbH
SERVICE MANUAL EXTRA 200
PAGE DATE: 1. July 1996
I M P O R T A N T Clamping has to be performed in accordance with the
Service Bulletin 300-1-93 and the Instruction No. 32 of
the National Telephone Supply Co., Cleveland Ohio.
I M P O R T A N T To prevent twisting the cables clamp the sleeves in the
same plane.
24 Consider that the clamping area shall be 30 cm aft the
rear pulley and clamp the sleeves.
25 Cut the free end of the cable (20 mm behind the sleeve).
26 Slip the shrinking sleeve on the rear sleeve and heat up
with a heat gun (The front sleeve can be left free for
visual control of the cable-to-cable connection).
27 Remove the front pedal securing device.
28 Follow the steps 3 to 27 for the RH control cable.
29 Remove rudder securing devices.
30 Check free travel of rudder.
27-21-06 Fairlead Removal/Installation
1 Remove the fairlead retaining clip.
2 Pull the fairlead halves out of the sleeve.
3 Reverse procedure to install the fairlead.
27-21-07 Rudder Rigging
N O T E Inspect the control cables, the pulleys, the fairleads and
the bottom hinge assembly (with the travel stop plate)
for signs of wear or damage before beginning any ad-
justments. Replace parts if necessary.
1 Secure the rudder pedals in neutral position.
2 Check if the rudder is in 0°-position. (Rudder horn lead-
ing edge in alignment with the leading edge of the ver-
tical stabilizer.)
MAINTENANCE PRACTICES
Control Cable Installation
