CHAPTER 28
PAGE 21
EXT
RA - FLUGZEUGBAU GmbH
SERVICE MANUAL EXTRA 200
PAGE DATE: 1. July 1996
28-21-05 Fuel Line Replacement
Refer to Figure 10A. The letters (A-J) refer to the markings
of Figure 7.
General information concerning hoses and fittings you find
in Chapter 20.
I M P O R T A N T If replacement of fuel lines passing the firewall is neces-
sary, renew the sealing of the rubber grommet grooves
and gaps at the engine side of the firewall. Use PRC-
812 (Products Research & Chemical Corporation, USA)
firewall sealant. Cover the fuel lines of the engine de-
partment with AEROQUIP AE102 fire sleeves as per
Chapter 20-10-07.
N O T E Use only, tubes and fittings as listed in the following.
MAINTENANCE PRACTICES
