CHAPTER 28
PAGE 24
EXT
RA - FLUGZEUGBAU GmbH
SERVICE MANUAL EXTRA 200
PAGE DATE: 1. July 1996
28-41-00 MAINTENANCE PRACTICES
28-41-01 Fuel Quantity Indicator
Removal/Installation
1 Disconnect battery.
2 Loosen the nuts, remove
the mounting bracket
and remove the fuel
quantity indicator.
3 Disconnect the wiring
(the lamp is not used).
4 Install in reverse se-
quence of removal ob-
serving the wiring dia-
gram.
