SERVICE MANUAL EXTRA 200
PAGE DATE: 1. July 1996
31-15-02 Front Instrument Panel
Removal/Installation
C A U T I O N Hold instruments and panel by hand to prevent from
falling down when removing the instrument panel at-
tachment screws.
1 Remove the AN526 C-1032-R6 instrument panel at-
tachment screws (3, Figure 4).
2 Disconnect the pitot resp. static lines from the instru-
ments (7). Mark lines for later identification.
3 Remove instrument panel (5) and frame (6).
4 Remove DIN 912 M4x20 screws (4) if removal of in-
struments is necessary.
5 Remove DIN 912 M4x5 bolts (2) and shock mounts
(1) with LN 9348 M4 stop nuts for disassembly of in-
strument panel and frame.
6 Reverse procedure for assembly/installation.
