Main Landing Gear Mounting
Figure 2
32-11-03 Tail spring
Removal/Installation
1 Shore the tail as per Chapter 07-20-02.
2 Remove the tail cone access panel per Ch. 51-00-01.
3 Disconnect connector spring kit (7, Figure 3) from the
rudder bottom hinge bellcrank by removing the attach-
ment bolts (8).
4 Remove the tail spring attachment bolts (1-3).
5 Remove the tail spring (4).
6 Disconnect the tail spring cuff (5) from the tail spring
by removing the bolts (12) and remove grease nipple if
necessary.
7 Reverse procedure for installation; consider to fasten
the breather line using the MS21919-DG12 clamp (6).
Install the lighter spring of the connector spring kit at
the left side.
MAINTENANCE PRACTICES
Top Half of the Mounting Clamp
