CHAPTER 32
PAGE 6
EXT
RA - FLUGZEUGBAU GmbH
SERVICE MANUAL EXTRA 200
PAGE DATE: 1. July 1996
MAINTENANCE PRACTICES
32-11-04 Tail Wheel Fork Assembly
Removal/Installation
1 Shore the tail as per Chapter 07-20-02.
2 Disconnect the connector spring kit (7, Figure 3) from
the rudder bootom hinge bellcrank by removing the
attachment bolts (8).
3 Remove the attachment stopnut (10) with washer and
steering arm (11) with the connector spring kit.
4 Turn wheel fork (15) to 90°-position to press pin (14)
inside.
W A R N I N G Prevent pin (14) from shooting out when appearing at
the bottom of the tail spring cuff (5) during removal of
the wheel fork by pressing it inside by finger.
5 Remove wheel fork with pin and spring (14).
6 Reverse procedure for assembly. Install the lighter
spring of the connector spring kit at the left side.
32-11-05 Tail Wheel
Disassembly/Assembly
1 Shore the tail as per Chapter 07-20-02.
2 Remove the attachment bolt (16, Figure 3), washers,
and stopnut.
3 Remove the tailwheel.
4 Disassemble the bearings (17), the wheel halves (18),
the spacer sleeve (19), and the solid ruber tire (20).
5 Reverse procedure for assembly.
