EXT
RA - FLUGZEUGBAU GmbH
SERVICE MANUAL EXTRA 200
CHAPTER 33
PAGE 6
PAGE DATE: 1. July 1996
3 Remove the AN 526 C 1032 R8 bolts (9, Figure 1) and
disconnect the ground bonding lead.
4 Pull out the power supply (10) 2 centimetres and re-
move.
C A U T I O N DC units are polarity sensitive. Black lead is negative.
5 Install in reverse sequence of removal observing De-
tail A of Figure 1 when attaching the power supply on
the attachment plate (11).
MAINTENANCE PRACTICES
