EXT
RA - FLUGZEUGBAU GmbH
SERVICE MANUAL EXTRA 200
CHAPTER 33
PAGE 5
PAGE DATE: 1. July 1996
33-41-00 MAINTENANCE PRACTICES
33-41-01 Navigation/Strobe Lights
Removal/Installation
W A R N I N G High Voltage! Wait 5 minutes after shutting off before
starting any work on the strobe light system.
1 Disconnect the battery and wait 5 minutes.
N O T E To change a navigation light bulb or glass the removal
of the AN 526 C Phillips screws (6, Fig. 1) is sufficient
for access.
2 Remove the lighting unit (1) in combination with the
wing tip panel (2) per Chapter 57.
3 Remove the lighting cover Phillips screws (6).
4 Remove the lighting cover and pull out the strobe light
(7) some centimetres.
5 Remove the lighting unit attachment bolts M4x12/20
(8).
6 Remove the lighting unit.
7 Install in reverse sequence of removal after applying
Silicon between the wing tip panel and the lighting unit.
33-41-02 Strobe Light Power Supply (Dual System)
Removal/Installation
W A R N I N G High Voltage! Wait 5 minutes after shutting off before
starting any work on the strobe light system.
1 Remove the wing tip attachment plate with the light-
ing unit per Chapter 33-41-01 following the steps 1 to 5.
2 Disconnect the electrical wiring of the power supply.
