GENERAL
Access Panel Identification
P
o
s
i
t
i
o
n
I
t
e
m
1 Top half of the engine cowling
2 Oil filler access door (non-removable)
3 Main fuselage cover
4 Instrument cover
5 Tail fairing
6 Tail cone access panel (RH)
7 Tail side skin (LH/RH)
8 Cuff (LH/RH)
9 Wheel speed fairing (LH/RH)
10 Bottom half of the engine cowling
11 Air inlet screen
12 Spinner
13 Exhaust area covering sheet
14 Bottom fuselage cover
15 LH wing tip panel
16 LH outbourd access panel
17 LH inboard access panel
18 RH inboard access panel
19 RH outboard access panel
20 RH wing tip panel
From Ser. No 27 item 13 is
attached to item 14 by rivets
