CHAPTER 51
PAGE 6
EXT
RA - FLUGZEUGBAU GmbH
SERVICE MANUAL EXTRA 200
PAGE DATE: 1. July 1996
51-10-00 INVESTIGATION
51-10-01 Damage Classification
W A R N I N G All damage of composite parts must first be classified
by qualified personnel. In case of doubt with regard to
the classification of damage, if a clear definition of the
extent of damage is not possible, or if a repair of dam-
age in spite of the valid manufacturer documentation
is doubtful, contact EXTRA-FLUGZEUGBAU GmbH.
W A R N I N G Only the Damages Classes 2, 3 and 4 may be repaired
by qualified personnel. In case of Damage Class 1 it
has to be contacted EXTRA-FLUGZEUGBAU GmbH.
According to the Luftfahrt-Bundesamt (Federal German
Aviation Authority) four damage classes are defined:
Damage Class 1:
Large scale destruction requiring a partial reconstruction of
the component or large scale repair. Each destruction over
300 mm diameter and each damage of a spar is a large scale
destruction. EXTRA-FLUGZEUGBAU GmbH has to be
contacted prior to repair.
Damage Class 2:
Damage to primary structures and to secondary structures to
the following extent: Holes and fractures extending through
a sandwich component and a scale under 300 mm diameter.
Damage Class 3:
Damage to primary structures and to secondary structures to
the following extent: Small holes or fractures in the external
covering layers, if not accompanied by damage to supporting
layers or internal covering layers.
