EXT
RA - FLUGZEUGBAU GmbH
SERVICE MANUAL EXTRA 200
CHAPTER 57
PAGE 10
PAGE DATE: 1. July 1996
57-35-00 MAINTENANCE PRACTICES
57-35-01 Wing Tip Panel
Removal/Installation (if dual strobe light and
navigation light system is installed) .
Refer to Figure 1 of Chapter 33.
W A R N I N G High Voltage! Wait 5 minutes after shutting off before
starting any work on the strobe light system.
1 Disconnect the battery and wait 5 minutes.
2 Remove the DIN 933 M6x20 bolt, the metal sheet
screws, the AN 526 C 1032 R8 bolts and the washers.
3 Tie out the wing tip panel with the lighting unit some
centimetres (Consider that the panel is sealed to the wing
tip with silicone).
4 Disconnect the electrical wiring and the ground bond-
ing lead by loosening the central M4 nut of the lighting
unit attachment.
5 Remove the wing tip panel.
6 Clean sealing surfaces mechanically and with Acetone.
7 Install in reverse sequence of removal after applying
Silicone to the sealing surfaces.
