EXT
RA - FLUGZEUGBAU GmbH
SERVICE MANUAL EXTRA 200
CHAPTER 57
PAGE 11
PAGE DATE: 1. July 1996
57-60-00 AILERONS
The ailerons are constructed in the same manner as the wing
but with single chamber spar. They are supported at three
points in spherical bearings pressed into aluminium brack-
ets. Furthermore the ailerons are equipped with "glass fibre
laminate spades" to decrease pilots forces.
The layer sequence of the ailerons is shown in Figure 4.
All composite parts, as protection against moisture and UV
radiation, are coated with an unsaturated polyester gel-
coat, an acrylic filler and finally with an acrylic paint.
For repair of composite parts refer to Chapter 51.
PAGE DATE: 1. June 1997
