CHAPTER 79
PAGE 3
EXT
RA - FLUGZEUGBAU GmbH
SERVICE MANUAL EXTRA 200
PAGE DATE: 1. JuLy 1996
79-00-00 GENERAL
The EXTRA 200 is equipped with a modification of a
Christen Inverted Oil System (CHRISTEN 801 series). The
need for modification of the standard Christen 801 Inverted
Oil System results from installation requirements for differ-
ent system components of the Lycoming AEIO-360-A1E
engine. Maintenance work or overhaul of the oil system
requires consultation of the manufacturer. (see Chapter 01).
The lubrication system of the EXTRA 200 is equipped with
an oil cooler (SW 8406 R) which is produced by the
STEWART WARNER SOUTH WIND Corporation.
I M P O R T A N T Before making installations and repairs to the aircraft
plumping, it is important to make accurate identifica-
tion of plumping materials. Refer to the respective Fig-
ures in this Chapter.
General information concerning flexible hoses, fire sleeves,
and fittings used in the Extra 200 oil system you find in
Chapter 20.
I M P O R T A N T If replacement of oil lines is necessary, cover the oil lines
of the engine department with AEROQUIP AE102 fire
sleeves as per Chapter 20-10-07 in case of AEROQUIP-
hoses are used (except the AEROQUIP 637/MIL-H 6000
hoses).
