CHAPTER 79
PAGE 5
EXT
RA - FLUGZEUGBAU GmbH
SERVICE MANUAL EXTRA 200
PAGE DATE: 1. JuLy 1996
1 AN 842-12D PN: PC-00175
2 AN 844-12D PN: PC-00881
3 AN 823-10D PN: PC-00165
4 AN 823-10D PN: PC-00165
5 AN 816-10D PN: PC-00157
6 AN 816-10D PN: PC-00157
7 Christen 804-S PN: PC-700031
8 AN 823-10D PN: PC-00165
9 LW-14148 PN: PC-700030
10 AN 823-10D (mod.) PN: PC-700029
11 AN 816-10D PN: PC-00165
Fittings of Inverted Oil System
Figure 2
