EXT
RA - FLUGZEUGBAU GmbH
SERVICE MANUAL EXTRA 200
CHAPTER 05
PAGE 17
PAGE DATE: 1. July 1996
Inspector:
Mechanic:
Date:
Serial No.:
Inspections
as specified
each 50 hours
each 100 hours
Fuel system
O O 1 Inspect the fuel lines for leaks, security, chafing, dents and
cracks. Replace fuel lines as required.
O O 2 Inspect fuel selector valve for operation and proper pointer
indication
O O 3 Drain fuel system
O O 4 Check acro- and center tank attachment
O O 5 Check acro-, center- and both wing tanks for leaks
O O 6 Check boost pump
O O 7 Check fuel filler caps for security and proper operation
O O 8 Check proper seat and condition of sealing lip
Flight controls
O O 1 Remove wing access panels.
O O 2 Inspect control surfaces for security of attachment, free
movement, dents, delaminations and cracks.
O O 3 Inspect elevator trim system for proper operation and rigging.
O O 4 Inspect hinges for condition, cracks and security; hinge bolts,
hinge bearings, self-locking nuts.
O O 5 Check free play in control system: torque tube, control
surfaces, control sticks, rod end bearing, deflector limiter.
O 6 Lubricate rear torque tube bearing. Remove bolt for greasing.
O O 7 Lubricate aileron rodend bearings, trim flap hinges and trim
lever bolt.
O 8 Lubricate adjustment tube of electrical pedal adjustment.
O O 9 Check rudder cable system including sleeves, fairleads,
pulleys and cable retracting springs per FAA-AC 43.13-1A.
SCHEDULED MAINTENANCE CHECKS
Maintenance Checks Schedule
