EXT
RA - FLUGZEUGBAU GmbH
SERVICE MANUAL EXTRA 200
CHAPTER 05
PAGE 18
PAGE DATE: 1. July 1996
Inspector:
Mechanic:
Date:
Serial No.:
Inspections
as specified
each 50 hours
each 100 hours
SCHEDULED MAINTENANCE CHECKS
Maintenance Checks Schedule
O 10 Check for minimum 3.5 mm (1/8") clearance of rudder pedal
versus safety stop when fully deflected for rudder cables
having 50 h flight time minimum. On newly installed rudder
cables the minimum spacing is 6 mm (1/4"). Refer to Figure 4.
This check is to be performed with zero loading on the rudder
pedals.
O 11 Rough check of safety stop clearance. With a force of approx.
90 kg (200 lbs) acting on the fully deflected rudder pedal the
safety stop shall not be reached. If the stop is reached the
control system indicates a too high flexibility which needs to
be traced. In this case contact EXTRA for advice.
O O 12 Inspect all flight control ventilation holes for obstruction.
O 13 Inspect elevator balance weight for looseness and condition.
O 14 Inspect push rods.
Landing gear
O O 1 Check landing gear for general condition.
O O 2 Check landing gear spring for dents and cracks.
O O 3 Inspect landing gear spring mounting clamps and bolts for
security.
O 4 Lubricate landing gear center bolt and landing gear bearings.
O 5 Check wheel rake (10° ± 0.5°) and toe-in (1.5° ± 0.5°) per
Chapter 32.
Fairings:
O O 1 Disassemble fairings.
O O 2 Check fairings for dents and cracks.
O O 3 Check fairing ventilation hole for obstruction.
