EXT
RA - FLUGZEUGBAU GmbH
SERVICE MANUAL EXTRA 200
CHAPTER 05
PAGE 26
PAGE DATE: 1. July 1996
Vertical Stabilizer
Leading edge
O 1 Check surface for erosion, scratches, stone nicks and impact dam-
ages.
O 2 Check bonding left/right for dents, cracks and delamination.
Front spar section
O 3 Check bonding skin/spar for delamination by coin tapping (Refer to
Chapter 20-10-05).
O 4 Detailed visual sheet metal attachment fitting for damage, corrosion
and link bolts security.
Rear spar section
O 5 Check bonding skin/spar for delamination by coin tapping .
O 6 Detailed visual rear spar web for dents, cracks and delamination. Pay
particular attention to the cut out for rudder cantilever.
O 7 Check steel sleeve for secure bonding to the spar.
O 8 Replace attachment bolts and stop nuts. Check for proper torque in
accordance with Chapter 20-10-02.
Root and Tip
O 9 Check root rib for cracks, delamination and secure bonding to skin
and spars by coin tapping.
O 10 Inspect tip rib visually for general condition.
Rudder
O 1 Check tip rib bonding to the skin laminate by coin tapping.
O 2 Check bonding skin/spar for delamination by coin tapping.
O 3 Check bonding trailing edge for cracks and delaminations by coin
tapping.
O 4 Detailed visual of mounting brackets for damages and cracks. Ensure
proper attachment. Replace bolts and stop nuts for new ones in any
case. Check for proper torque in accordance with Chapter 20-10-02.
O 5 Check actuator lever for damage, cracks and proper attachment.
O 6 Inspect ventilation holes visually for obstruction. Refer to Chapter
05-20-01, Figure 2 "Drain and Vent Holes".
Inspector:
Mechanic:
Inspections
Date:
Serial No.:
1000 hours
SCHEDULED MAINTENANCE CHECKS
Significant Items Inspection
